  3. Uninterruptible Power Supply (UPS)
Application Scenarios
UPS Series Selection Guide
UPS systems use AC input, converted to DC via AC/ DC rectifiers, then inverted back to AC via DC/AC inverters. Efficiency ranges from 90%~94% (high frequency UPS >95%).

New modular high-frequency UPS power supplies place strict demands on bus electrolytic capacitors for high frequency/low impedance, high capacitance density, and parameter uniformity.

Power Snap-in
Series		 Voltage
 (V)		 Capacitance
 (µF )		 Dimensions
(mm)		 Configuration Total Qty
(pcs)
(Parallel/Series)
10KW LH 450 470 30 * 50 2 Parallel 2
20KW LG 450 470 30 * 50 2S2P 4
100KW LR 450 820 35 * 50 2S18P 36
100KW LQ 450 390 35 * 50 2S17P 34
125KW GS 450 1500 40 * 70 2S12P 24
125KW LR 450 820 35 * 50 2S18P 36
200KW LR 450 1200 35 * 70 2S20P 40
